Adjustable Decking Risers - Arkimede 60 | 60 to 115 mm?noresize

1 /

Product Description

 close-icon minus-icon

ARKIMEDE 60 Decking risers with adjustable height starting from 60 mm (extensions excluded).

Base laying surface: 314 cm2. Head diameter: 120 mm with a laying surface of 113 cm2.

Box is composed by the base, rotating ring and head with 1 tab for joists.

The base facilitates efficient water drainage.

• Extensions of h. 50 and h.100mm are available as options.

Materials used

 close-icon minus-icon

Made of PP (polypropylene).

Installation

 close-icon minus-icon

Used in external areas for the creation of decks, terraces, and pavements.

Articles

minus-icon
Product Code/Name Download Dimension Article Info
ARKIMEDE 60 Decking Enlarge search-icon
TER09-1163/1A

ARKIMEDE 60 Decking

close-icon
TD 		da 60 a 115 mm

Download Legends

TD

TD

Technical Datasheet
