Classification and standards

Paving

Product Description

 close-icon minus-icon
Leveling rubber disc for sloping compensation. Diameter 120 mm, available in 3 different sizes for 1%, 3% and 5% slopes.

Materials used

 close-icon minus-icon
Made of thermoplastic rubber (TPE). ""

Use

 close-icon minus-icon
Clever allows the compensation of slopes from 1% up to 5%. Just put it on the head of the support and twist it for final regulation. Clever guarantees to have a perfectly flat surface and to reduce walkover noise.

Articles

minus-icon
Product Code/Name Download Dimension Article Info
Clever - 1 % slope regulator Enlarge search-icon
TER09-1143/C1

Clever - 1 % slope regulator

close-icon
TD 		ø 120 mm
Clever - 3 % slope regulator Enlarge search-icon
TER09-1143/C3

Clever - 3 % slope regulator

close-icon
TD 		ø 120 mm
Clever - 5 % slope regulator Enlarge search-icon
TER09-1143/C5

Clever - 5 % slope regulator

close-icon
TD 		ø 120 mm

Download Legends

TD

TD

Technical Datasheet
