Dakua shower channel
Canaletta dakua con griglia inox obli
Linear Shower Drain with Stainless Steel Grate - Dakua+ Oblì?noresize
Linear Shower Drain with Stainless Steel Grate - Dakua+ Oblì
Linear Shower Drain with Stainless Steel Grate - Dakua+ Oblì
Linear Shower Drain with Stainless Steel Grate - Dakua+ Oblì

1 /

Product Description

 close-icon minus-icon

The DAKUA+ linear shower drain range guarantees high functionality combined with a modern aesthetic. This model can be placed as desired. The block body shower channel drain is made of AISI 304 stainless steel that, thanks to the absence of bends, welds and screws, ensures an easy cleaning for high hygiene standards.

The flow rate (44 litres/min) is high, even with lowered heights. All gratings are interchangeable and available in polished, brushed steel or glass. The kit is composed of:

- A preassembled grating, ready for installation.

- A waterproof polyester sheet , shaped on the edge of the channel.

- A shower channel body and a stainless steel grating with glass coating.

- ABS siphoned cup with joint and gasket

This shower channel is suitable for flat flooring and open showers, improves the aesthetics of the bathroom's floor surface whilst effectively collecting used shower waters.

Materials used

 close-icon minus-icon

Stainless steel (channel and grating) - ABS (siphon and outlet body) - Waterproof polyester fabric (waterproofing sheet)


Use

 close-icon minus-icon

Dakua+ shower channels are used for the collection of used shower water. It fits perfectly with the floor embellishing the surface aesthetics.


Articles

minus-icon
Product Code/Name Download Dimension Article Info
Kit - channel dakua+ with stainless steel grating oblì - 600 Enlarge search-icon
POZ93-118600/R

Kit - channel dakua+ with stainless steel grating oblì - 600

close-icon
TD 		78 x 600 mm
Kit - channel dakua+ with stainless steel grating oblì - 700 Enlarge search-icon
POZ93-118700/R

Kit - channel dakua+ with stainless steel grating oblì - 700

close-icon
TD 		78 x 700 mm
Kit - channel dakua+ with stainless steel grating oblì - 800 Enlarge search-icon
POZ93-118800/R

Kit - channel dakua+ with stainless steel grating oblì - 800

close-icon
TD 		78 x 800 mm
Kit - channel dakua+ with stainless steel grating oblì - 900 Enlarge search-icon
POZ93-118900/R

Kit - channel dakua+ with stainless steel grating oblì - 900

close-icon
TD 		78 x 900 mm

Download Legends

TD

TD

Technical Datasheet

Do you need product support?

Request a sample or contact us for any need.
