Fiber glass mesh for etics
Reti per cappotto optima 160
Insulation Netting in Fiberglass

1 /

Product Description

 close-icon minus-icon

Anti-cracking fiberglass mesh for “a cappotto” insulation, made of E-glass fiber with anti-alkaline sizing equal to 20%, raw fabric weight equal to 131 gr. The weight of the treated fabric is 160 gr/m2 (with an appreciable deviation of 5%).
Mesh size should be 3,5 x 4,0 mm.
The mesh must be placed in the layer of adhesive, making sure that it is perfectly embedded using a notched trowel or float. The superimpositions of the various layers of net must never be less than 10 cm.
The surface so obtained must be further smoothed and levelled in order to receive, once cured, the further coat of gravel plaster and painting.
In yard the net will be delivered in incelophanati rolls, bearing a control code and sheet with an outline description of the product.
The dimensions of the roll are equal to 1.00 m in height by 50 m in length.
Used in thermal insulation systems, ETICS, as reinforcement of the smoothing layer in order to absorb and evenly distribute the mechanical stresses to which the system may be subjected.


Materials

 close-icon minus-icon

Made of fiberglass type E, impregnated with anti-alkaline resins SBR and weight of 160 gr/m2.
The net is available in different colors or with different brands (Optima, Optimax, Optinet, Optimesh or other customizations

Installation

 close-icon minus-icon

Used in thermal insulation systems, ETICS, as reinforcement of the smoothing layer in order to absorb and evenly distribute the mechanical stresses to which the system may be subjected.

Articles

minus-icon
Product Code/Name Download Dimension Article Info
RET01-1172E

Fiber Glass Net Optima 160

close-icon
TD 		1,00 x 50 m
RET01-1172ED

Fiber Glass Net Optima 160

close-icon
TD 		1,00 x 50 m
RET01-1172EDN

Fiber Glass Net Optima 160

close-icon
TD 		1,00 x 50 m
RET01-1172EV

Fiber Glass Net Optima 160

close-icon
TD 		1,00 x 50 m

Download Legends

TD

TD

Technical Datasheet
