Insulation Netting in Fiberglass

1 /

Product Description

 close-icon minus-icon

Fiberglass net for "a coat" insulation, made of glass fibers and with anti-hatching priority of 20%, weight of the raw fabric of 131 gr. The weight of the treated tissue is equal to 160 gr / m2 (with a 5% appreciable scrap).
The size of the mesh must be equal to 3.5 x 4.0 mm. The aforementioned network must be placed in the layer of adhesive, being careful to the fact that it is perfectly drowned using for this purpose a toothed spatula or a trowel. The overlaps of the various network layers must never be less than 10 cm.
The surface thus obtained should be further shaved and leveled in order to receive the further hand of plaster in gravel and painting.
In the construction site, the network will be delivered in the Incelophanate roll, bearing a control code and sheet with a maximum description of the product.
The size of the roll are 1.00 m high for 50 m long.
Used in the thermo-insulating coat systems, ETICS, as a reinforcement layer armor in order to absorb and distribute the mechanical stresses evenly to which the system can be subject.

Materials used

 close-icon minus-icon

Made of glass fiber adfors Saint-Gobain type and, impregnated with antialcaline SBR resins and weight equal to 160 gr / m2.

Use

 close-icon minus-icon

Used in the thermo-insulating coat systems, ETICS, as a reinforcement layer armor in order to absorb and distribute the mechanical stresses evenly to which the system can be subject.

Articles

minus-icon
Product Code/Name Download Dimension Article Info
Fiber Glass Net Optima 150 Enlarge search-icon
RET01-1160E

Fiber Glass Net Optima 150

close-icon
TD 		1,00 x 50 m
Fiber Glass Net Optima 160 Enlarge search-icon
RET01-1172E

Fiber Glass Net Optima 160

close-icon
TD 		1,00 x 50 m

Download Legends

TD

TD

Technical Datasheet
