Undersill Drip Profile with Fiberglass Mesh?noresize

1 /

Product Description

 close-icon minus-icon

Junction profile, pre-drilled on the side toward the wall, shaped to protect insulating panels (thickness 0,5 - 0,8 - 1,2 mm).

Materials used

 close-icon minus-icon

Made of aluminum.

Use

 close-icon minus-icon

Utilized to cover and protect the insulation board at the sub-window and the window sill.

Articles

minus-icon
Product Code/Name Download Dimension Article Info
Cover bead with drip Enlarge search-icon
ZIN32-1680/S

Cover bead with drip

close-icon
TD 		50 x 2.500 mm
Cover bead with drip Enlarge search-icon
ZIN32-1680/S1

Cover bead with drip

close-icon
TD 		80 x 2.500 mm
Cover bead with drip Enlarge search-icon
ZIN32-1680/S2

Cover bead with drip

close-icon
TD 		120 x 2.500 mm

Download Legends

TD

TD

Technical Datasheet

Do you need product support?

Request a sample or contact us for any need.
