Fireproof Drywall Trap Door

1 /

Product Description

 close-icon minus-icon

Fire resistant 30/90 minute inspection hatch (EI30 and EI90), with automatic fire closure with handgrip for ease of use.
Easy and quick mounting both in key structural walls and not.
Individually packed in boxes.

Materials

 close-icon minus-icon

Aluminum frame, plasterboard panel and fire resistant protection.

Installation

 close-icon minus-icon

Used in crawl spaces and walls with fire protection F30/EI30 and EI90 (E = aptitude to block or produce flames, vapors or hot gases on the expo- sed side; I = aptitude to reduce heat transmission.)

Articles

minus-icon
Product Code/Name Download Dimension Article Info
GAN01-6520

AluRapid EI30 with fire flame retardant bulkhead

300 x 300 mm
GAN01-6522

AluRapid EI30 with fire flame retardant bulkhead

close-icon
TD 		400 x 400 mm
GAN01-6524

AluRapid EI30 with fire flame retardant bulkhead

close-icon
TD 		500 x 500 mm
GAN01-6526

AluRapid EI30 with fire flame retardant bulkhead

close-icon
TD 		600 x 600 mm
GAN01-6528

AluRapid EI30 with fire flame retardant bulkhead

close-icon
TD 		600 x 800 mm
GAN01-6530

AluRapid EI30 with fire flame retardant bulkhead

close-icon
TD 		600 x 1.000 mm
GAN01-6540

AluRapid F30/EI30 with fire flame retardant bulkhead

close-icon
TD 		300 x 300 mm
GAN01-6540F120

close-icon
TD
GAN01-6542

AluRapid F30/EI30 with fire flame retardant bulkhead

close-icon
TD 		400 x 400 mm
GAN01-6542F120

close-icon
TD 		400 x 400 mm
GAN01-6544

AluRapid F30/EI30 with fire flame retardant bulkhead

close-icon
TD 		500 x 500 mm
GAN01-6544F120

close-icon
TD 		500 x 500 mm
GAN01-6546

AluRapid F30/EI30 with fire flame retardant bulkhead

close-icon
TD 		600 x 600 mm
GAN01-6546F120

close-icon
TD 		600 x 600 mm
GAN01-6548

AluRapid F30/EI30 with fire flame retardant bulkhead

close-icon
TD 		600 x 800 mm
GAN01-6548F120

close-icon
TD 		600 x 800 mm
GAN01-6550

AluRapid F30/EI30 with fire flame retardant bulkhead

close-icon
TD 		600 x 1.000 mm
GAN01-6550F120

close-icon
TD 		600 x 1.000 mm

Download Legends

TD

TD

Technical Datasheet
