Inspection Door Alumatic F30/EI30, F90/EI90


Request information
Print
  • Certifications
  • Product sheet
  • Articles
  • Related products
  • Accessories
  • Similar products
  • Share on

Product sheet

Description

30/90 minutes fire resistant inspection hatch (F30/EI30 and F90/EI90) with b fire protection on both sides.
Mounting in not structural walls, partitions of rooms also metallic.
Hidden snap closure.
Panel with anti-fall device.
Approved according to DIN 4102-2 or DIN EN 1364-1 with coating on both sides.
Individually packed in boxes.

Material

Aluminum frame, plasterboard panel and fire resistant protection.

Use

Used in crawl spaces, dividing walls and walls with fire protection F30/EI30 and F90/EI90 (E = aptitude to block or produce flames, vapors or hot gases on the exposed side; I = aptitude to reduce heat transmission.)

Articles

Code
Commercial Description
Dimensions
Q.ty/pkg
Q.ty/pallet
Selling Unit

GAN01-6600
Alumatic F30/EI30 with fire protection on both sides
12,5 mm 300 x 300 mm
-
25 KAR
PZ

GAN01-6602
Alumatic F30/EI30 with fire protection on both sides
12,5 mm 400 x 400 mm
-
30 KAR
PZ

GAN01-6604
Alumatic F30/EI30 with fire protection on both sides
12,5 mm 500 x 500 mm
-
18 KAR
PZ

GAN01-6606
Alumatic F30/EI30 with fire protection on both sides
12,5 mm 500 x 600 mm
-
1 KAR
PZ

GAN01-6607
Alumatic F30/EI30 with fire protection on both sides
12,5 mm 600 x 600 mm
-
1 KAR
PZ

GAN01-6608
Alumatic F30/EI30 with fire protection on both sides
12,5 mm 500 x 800 mm
-
1 KAR
PZ

GAN01-6610
Alumatic F30/EI30 with fire protection on both sides
12,5 mm 500 x 1.000 mm
-
9 KAR
PZ

GAN01-6650
Alumatic F90/EI90 with fire protection on both sides
25 mm 300 x 300 mm
-
72 KAR
PZ

GAN01-6652
Alumatic F90/EI90 with fire protection on both sides
25 mm 400 x 400 mm
-
36 KAR
PZ

GAN01-6654
Alumatic F90/EI90 with fire protection on both sides
25 mm 500 x 500 mm
-
30 KAR
PZ

GAN01-6656
Alumatic F90/EI90 with fire protection on both sides
25 mm 500 x 600 mm
-
15 KAR
PZ

GAN01-6657
Alumatic F90/EI90 with fire protection on both sides
25 mm 600 x 600 mm
-
23 KAR
PZ

GAN01-6658
Alumatic F90/EI90 with fire protection on both sides
25 mm 500 x 800 mm
-
9 KAR
PZ
