fiberglass mesh Premium Net ETAG 004

Product Description

fiberglass mesh available in various colors (identification code. R117, corresponding to net weight per square meter of fiberglass mesh without resin). Height 1,10 x 50 meters. Packed in cellophane rolls.

Materials used

Made of fiber-glass Adfors Saint-Gobain type E, impregnated with antialcaline resins SBR, complies with ETAG 004 certified by leading European Institutes, accompanied by Quality Mark ITC CNR, axle spacing 4.0 x 4.5 mm and weight equal to 150 gr/m2.

Use

Used in thermal insulating systems, ETICS as armor for the smoothing layer in order to absorb and evenly distribute the mechanical stresses to which the system could be subjected (ground settling, shrinkage, temperature changes, external agents) avoiding the formation of cracks in the facade.

Articles

Product	Code/Name	Download	Dimension
Enlarge	RET01-1160 White fiber glass mesh + logo	TD	1,10 x 50 m
Enlarge	RET01-1160A Orange fiber glass mesh	TD	1,10 x 50 m
Enlarge	RET01-1160B Blue fiber glass mesh	TD	1,10 x 50 m
Enlarge	RET01-1160G Yellow fiber glass mesh	TD	1,10 x 50 m
Enlarge	RET01-1160N White fiber glass mesh	TD	1,10 x 50 m
Enlarge	RET01-1160R Red fiber glass mesh	TD	1,10 x 50 m
Enlarge	RET01-1160GG Grey fiber glass mesh	TD	1,10 x 50 m
Enlarge	RET01-1160V Green fiber glass mesh	TD	1,10 x 50 m
