Fiber glass mesh for etics
Fiber glass mesh mega net hobby net meg ten etag 004 itc cnr 150 gr r117
Fiberglass Thermal Insulation Mesh
Fiberglass Thermal Insulation Mesh

1 /

Product Description

 close-icon minus-icon

White fiberglass mesh (identification code R117, corresponding to net weight per square meter of fiberglass mesh without resin), with overlap and cut lines to facilitate the correct installation. Height 1,10 x 50/25/10 meters. Packed in cellophane rolls.

Materials used

 close-icon minus-icon

Made of fiber glass Adfors Saint-Gobain type E, impregnated with anti alkaline resins SBR, it complies with ETAG 004 certified by leading European Institutes, accompanied by Quality Mark ITC CNR, axle spacing 4,0 x 4,5 mm and weight equal to 150 gr/m2.

Use

 close-icon minus-icon

Used in thermal insulating systems ETICS, as armor for the smoothing layer in order to absorb and evenly distribute the mechanical stresses to which the system could be subjected (ground settling, shrinkage, temperature changes, external agents) avoiding the onset of cracks in the facade.

Articles

minus-icon
Product Code/Name Download Dimension Article Info
Mega-Net fiber glass mesh for wall insulation Enlarge search-icon
RET01-1160DK

Mega-Net fiber glass mesh for wall insulation

close-icon
TD 		1,10 x 50 m
Hobby-net fiber glass mesh for wall insulation Enlarge search-icon
RET01-1160DK25

Hobby-net fiber glass mesh for wall insulation

close-icon
TD 		1,10 x 25 m
Mega ten fiber glass mesh for wall insulation Enlarge search-icon
RET01-1160DK10

Mega ten fiber glass mesh for wall insulation

close-icon
TD 		1,10 x 50

Download Legends

TD

TD

Technical Datasheet
